FEATURES

• Available in white, outdoor white, 80-CRI, 90-CRI white, royal

blue, blue, green, PC amber, amber, red-orange, red, photo

red, far red & S Line far red

• ANSI-compatible chromaticity bins

• White binned at 85 °C

• Maximum drive current: royal blue, blue 1.2 A, others 1.5 A

• Low thermal resistance: as low as 1.4 °C/W

• Wide viewing angle: 105°-140°

• Unlimited floor life at ≤ 30 °C/85% RH

• Reflow solderable - JEDEC J‑STD‑020C compatible

• Electrically neutral thermal path

• RoHS and REACH compliant

• UL® recognized component (E349212)
