FEATURES

• Available in white, outdoor white and 80-, 85- and 90-CRI white

• ANSI-compatible chromaticity bins

• Broadcast color option at 5700 K

• Binned at 85 °C

• Maximum drive current: Standard: 1500 mA, HE: 2000 mA

• Low thermal resistance: Standard: 4 °C/W, HE: 3 °C/W

• Wide viewing angle: Standard: 120°, HE: 125°

• Unlimited floor life at ≤ 30 ºC/85% RH

• Reflow solderable - JEDEC J‑STD‑020C

• Electrically neutral thermal path

• RoHS and REACh compliant

• UL® recognized component (E349212)

XPGBWT-01-0000-00GD3 XPGBWT-01-0000-00HE4 XPGBWT-01-R250-00EC1 XPGBWT-H1-R250-00BF8

XPGBWT-H1-R250-00BZ8 XPGBWT-H1-R250-00CE8 XPGBWT-H1-R250-00DF6 XPGBWT-L1-0000-00F51

XPGBWT-L1-R250-00DZ5 XPGBWT-L1-R250-00FE3 XPGBWT-01-0000-00ED5 XPGBWT-01-R250-00GE4

XPGBWT-H1-0000-00EF6 XPGBWT-H1-R250-00CZ6 XPGBWT-L1-R250-00EZ5 XPGBWT-L1-R250-00FE1

XPGBWT-01-0000-00FC1 XPGBWT-01-0000-00FD1 XPGBWT-01-0000-00FE6 XPGBWT-01-0000-00FF5 XPGBWT01-0000-00HD1 XPGBWT-01-R250-00FD3 XPGBWT-H1-0000-00DE5 XPGBWT-H1-R250-00EF6 XPGBWT-L1-

0000-00FE4 XPGBWT-L1-0000-00HE1 XPGBWT-L1-R250-00FF5 XPGBWT-L1-R250-00CZ7 XPGBWT-01-0000-

00FC5 XPGBWT-01-0000-00GD2 XPGBWT-01-0000-00HE3 XPGBWT-01-R250-00GD1 XPGBWT-H1-0000-00DE7

XPGBWT-H1-0000-00EE5 XPGBWT-H1-R250-00CF8 XPGBWT-L1-0000-00CF8 XPGBWT-L1-R250-00DF5

XPGBWT-L1-R250-00DZ6 XPGBWT-L1-R250-00DZ7 XPGBWT-01-0000-00DC5 XPGBWT-01-0000-00DC6

XPGBWT-01-0000-00DD5 XPGBWT-01-0000-00DF6 XPGBWT-01-0000-00EC1 XPGBWT-01-0000-00EC2

XPGBWT-01-0000-00EC3 XPGBWT-01-0000-00EC4 XPGBWT-01-0000-00EC5 XPGBWT-01-0000-00EC6

XPGBWT-01-0000-00ED1 XPGBWT-01-0000-00ED2 XPGBWT-01-0000-00ED3 XPGBWT-01-0000-00ED4

XPGBWT-01-0000-00EE3 XPGBWT-01-0000-00EE4 XPGBWT-01-0000-00EE6 XPGBWT-01-0000-00EF4 XPGBWT01-0000-00EF5 XPGBWT-01-0000-00EF6 XPGBWT-01-0000-00FC2 XPGBWT-01-0000-00FC3 XPGBWT-01-0000-

00FC4 XPGBWT-01-0000-00FC6 XPGBWT-01-0000-00FD2 XPGBWT-01-0000-00FD3 XPGBWT-01-0000-00FD4

XPGBWT-01-0000-00FD5 XPGBWT-01-0000-00FE3 XPGBWT-01-0000-00FE4 XPGBWT-01-0000-00FE5 XPGBWT01-0000-00FF4 XPGBWT-01-0000-00FF6 XPGBWT-01-0000-00GC1 XPGBWT-01-0000-00GC2 XPGBWT-01-0000-

00GC4 XPGBWT-01-0000-00GC5 XPGBWT-01-0000-00GD1 XPGBWT-01-0000-00GD4 XPGBWT-01-0000-00GE3

XPGBWT-01-0000-00GE4 XPGBWT-01-0000-00GE5 XPGBWT-01-0000-00GF4 XPGBWT-01-0000-00GF5

XPGBWT-01-0000-00HC1 XPGBWT-01-0000-00HC2 XPGBWT-01-0000-00HF4 XPGBWT-01-R250-00DC5

XPGBWT-01-R250-00DC6 XPGBWT-01-R250-00DD5 XPGBWT-01-R250-00DE6 XPGBWT-01-R250-00DF6

XPGBWT-01-R250-00EC2 XPGBWT-01-R250-00EC3 XPGBWT-01-R250-00EC4 XPGBWT-01-R250-00EC5

XPGBWT-01-R250-00EC6 XPGBWT-01-R250-00ED1 XPGBWT-01-R250-00ED2 XPGBWT-01-R250-00ED3

XPGBWT-01-R250-00ED4
