LA G6SP.01 - Dual binning

Advanced Power TOPLED®

Latest version of Advanced Power TOPLED with

increased brightness and improved thermal management.

— Signalling

Features:

— Package: white SMT package, colorless clear silicone resin

— Chip technology: Thinfilm

— Typ. Radiation: 120° (Lambertian emitter)

— Color: λdom = 617 nm (● amber)

— Corrosion Robustness Class: 3B

— Qualifications: AEC-Q102 Qualified with RV-level 1

— ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
Ordering Information

Type Luminous Intensity 1) Luminous Intensity 1) Ordering Code

I

F = 10 mA I

F = 140 mA

I

v I

v

LA G6SP.01-U1V1-1-1+8D6F-24-G3R3 450 ... 900 mcd 6.3 ... 14.0 cd Q65112A5883
