SYNIOS® P2720

KR DMLN31.23

This compact LED device is part of the SYNIOS P2720 family.

Given the scalability of this product family, it provides full performance and flexibility with just one footprint.

The KR DMLN31.23 product is meant to provide superior light

quality in ¼ mm² chip size class.

Applications

- Static Signaling

Features

- Package: SMD epoxy package

- Chip technology: Thinfilm

- Typ. Radiation: 120° (Lambertian emitter)

- Color: λdom = 621 nm (● red)

- Corrosion Robustness Class: 3B
- Qualifications: AEC-Q102 Qualified with RV-level 1

- ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
Ordering Information

Type Luminous Flux 1) Ordering Code

I

F = 200 mA

ΦV

KR DMLN31.23-GYJY-26-J3T3 21.0 ... 61.0 lm Q65112A9476
