DISPLIX® P3333

KRTB LSLPS1.32

This device is especially designed for full color RGB applications. The 6-lead technology allows for an additive mixture of

color stimuli by independent driving of each chip.

Applications

- Entertainment

- Indoor Lighting

- Projection & Display

Features

- Package: white PLCC-6 package, diffused silicone resin, black surface

- Chip technology: Thinfilm / UX:3 / InGaN on Sapphire

- Typ. Radiation: 120° (Lambertian emitter)

- Color: λdom = 621 nm (● red); λdom = 532 nm (● true green); λdom = 467 nm (● blue)

- ESD: 500 V acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 1B)

Ordering Information

Type Brightness 1) Ordering Code

KRTBLSLPS1.32-VUVX-EQ+BTBV-D8+TXUV-L1-B Q65113A3080

● red ● Iv

= 800 ... 1250 mcd (IF = 20 mA) Q65113A3080

● true green ● Iv

= 1902 ... 2800 mcd (IF = 20 mA) Q65113A3080

● blue ● Iv

= 377 ... 710 mcd (IF = 20 mA)
