GY CSHPM1.23

OSLON® SSL 150

New, higher performing OSLON SSL family LED with

well known superior robustness, high reliability, long

lifetime, low thermal resistance. Perfectly addressing

applications demanding for high efficiency and long

lifetime requirement.

— Architecture

— Architecture / Garden Lighting (LED & Laser)

— Medical Illumination

— Photo Therapy

Features:

— Package: SMT ceramic package with silicone lens

— Typ. Radiation: 150°

— Corrosion Robustness Class: 3B

— Lumen maintenance: Test results according to IESNA LM-80 available

— ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)

— Luminous Flux: typ. 84 lm

— Luminous efficacy: typ. 109 lm/W
Ordering Information

Type Luminous Flux 1) Ordering Code

I

F = 350 mA

ΦV

GY CSHPM1.23-KQKS-36 76.3 ... 97.0 lm Q65112A0763

GY CSHPM1.23-KRKT-36 82.0 ... 104.2 lm Q65113A3837
