规格书下载: https://look.ams-osram.com/m/4324650a82ec26a9/original/KR-DMLQ32-23.pdf

Description

This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint. The KR DMLQ32.23 product is meant to provide superior light quality in ½ mm² chip size class. The next generation SYNIOS® P2720 Kx DMLQ32.23 delivers higher performance, while remaining fully footprint- and solder pad-compatible to the previous version.

Features- Package: white SMT package, colorless clear silicone resin- Chip technology: Thinfilm- Typ. Radiation: 120° (Lambertian emitter)- Color: λdom = 621 nm (● red)- Corrosion Robustness Class: 3B- Qualifications: AEC-Q102 Qualified with RV-level 1- ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 2)
