规格书下载: https://look.ams-osram.com/m/3a705dc5b3d15a24/original/KW3-C3LPL3-TK.pdf

Description

The OSLON® Submount PL is able to meet a wide range of requirements in terms of output and adaptability to ambient conditions. It offers a uniform light pattern, thermal stability and great brightness.

Applications- Dynamic Forward Lighting - Static Forward LightingFeatures- Package: compact lightsource in multi chip on board technology- Chip technology: UX:3- Typ. Radiation: 120° (Lambertian emitter)- Color: Cx = 0.318, Cy = 0.331 acc. to CIE 1931 (● white)- Corrosion Robustness Class: 3A- Qualifications: AEC-Q102 Qualified- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)- Color over angle: Better than passus 3.7.2.1 of supplement proposal 7 to ECE reg. 128
